LS32 is an electronic control and motor two-in-one product developed by our company for microvan models.
Features
( 1 ) Miniaturization
The electronic control and motor integration solution saves the three-phase line, and the electronic control and motor share the same housing and water channel, which is miniaturized and improves the usability of the product . Lift.
( 2 ) Performance improvement
use TC275 triple-core chip, added functions such as arbitrary trailer and fault limp, and the software fault diagnosis was upgraded.
NVH Improved performance, near field 10cm Peak torque main order noise ≤ 95db , the noise increases linearly with the speed, no protrusion Peak, software noise reduction, jitter suppression.
Full-scenario torque safety strategy.
( 3 ) Reliability
Assembly 10.95g vibration standard, meeting the requirements of integrated bridge applications.
8 years or 30 Design life of 10,000 years.
For integrated bridge applications, reliability verifications such as ice water impact and gravel impact are added.
( 4 ) Scalability
PN power terminal, default IPT , connectors are optional.
Optional cover open interlock to meet stricter regulatory requirements.
The product has optional internal and external splines, and the default is internal splines.
ASIl C functional safety version is optional.
EMC level, high voltage conduction default CLASS 1 , CLASS 3 optional.
