Battery Materials List

Battery box : 1593 * 660 * 181.5mm 2
Sampling unit module: 72 string slave (BMU) 1 × 2
1P17S-105AH module: EVE Energy LFP105AH battery cell, 1P17S 2
1P18S-105AH module: EVE Energy LFP105AH battery cell, 1P18S 4
Power connector socket negative pole: TL 00Y-201-10 M8 1
Positive pole of power connector socket: TL 00X-201-10 M8 1
Communication connector socket: XT08X-P8/gray 1
Fuse fusion: EV315-L-3E50A 1
Main control unit module: TKB18_SCU 1
Insulation detection module: TKB-BMS-IMU 1
Current sensor: FS400E2T 1
MSD/Maintenance Switch: Amphenol MINI-MSDF000-F350A-750V-1
Negative input socket: TL 00Y-201-10 M8 1
Positive input socket: TL 00X-201-10 M8 1
Positive output socket: TL 00U-201-10 M8 1
Negative output socket: TL 00V-201-10 M8 1
DCDC socket: XL 082X -61-4 1
Slow charging socket: XL 082Y -61-4 1
Compressor socket: XL 082U-61-4 1
Communication interface: XT08X-P21/gray

Battery packs parameters

Rated voltage: 339.2V
Rated capacity :105Ah
The working voltage: range of the battery pack is 280V~408.8V
Total energy: 35.616KWh
Maximum continuous charging current: 40A
Maximum continuous discharge current: 105A
Peak discharge current: 210A
Environmental relative humidity: 25~85% RH
Cooling method: natural cooling
System operating temperature range:

Environmental temperature: The battery system can operate normally in an external environment temperature range of 0 ℃~45 ℃;
Charging temperature: When the internal ambient temperature of the battery pack is between 0 ℃ and 55 ℃, charging is acceptable;
Discharge temperature: When the internal ambient temperature of the battery pack is between -20 ℃ and 60 ℃, it can be discharged;
Full load operating temperature: When the internal ambient temperature of the battery pack is between 10 ℃ and 45 ℃, and the SOC is between 30% and 100%, the discharge power is not affected.
Factory insulation resistance test value (M Ω) ≥ 30
