Complete 24V 250W DC motor transaxle drive train kit. Includes EM brake, Curtis 70A controller, gear ratio and length of transaxle is adjustment, and DC-DC converter. Ideal for wheelchairs, mobility scooters, warehouse trolleys & industrial machines.
Upgrade your off-road or utility vehicle with our 40KW rated (65KW peak) PMSM motor kit, engineered for UTVs, mini trucks, and compact commercial EVs. This 144V liquid-cooled system delivers 105N.m rated torque (252N.m peak) for exceptional hill-climbing and load-carrying capability, all while maintaining ≥95% efficiency for extended range.
Perfect For:
✔ UTV/ATV Electric Conversions
✔ Mini Trucks & Utility Vehicles
✔ Agricultural & Industrial EVs
✔ Off-Road & Recreational Applications
🔧 Plug-&-Play Compatibility
108-180V DC Voltage Range – Works with most Li-ion battery packs
S9 Duty Cycle – Optimized for intermittent high-power demands
input ：200-240V AC output ：72V 25A input plug we prepare per your country type. input cable length 2m, Out put cable 500mm length, Andersen plug to lithium battery. dimension: see the drawing. Usage: Lithium battery type
Right side： plastic throttles, left and right a set. specially for tricycles. functions: Right hand throttle for accelerating, with Reverse and Forward gear stall switch, with front light on and off switch. Diameter of the installation hole：22Mm. installation metal tube diameter. Voltage : 5 V three wires of throttle left side: Turning lights (left and […]
Length ：1250MM, Leaf spring distance ：780mm, axle ratio: two can switch, one 11:1, one 22:1, so it can support vehicle run at fast speed and climbing. Loading capacity: 1.5 Tons vehicles. Brake type: hydraulic brake. PCD: 5*139.7
This controller is compatible with our 72V PMSM 7.5KW motor. It has a rated battery input voltage of 72V, with an input voltage range of 60-90V. The rated output current is 140A, and the maximum output current is 400A. The rated capacity is 12KVA, with a maximum capacity of 35KVA. It boasts a protection rating of IP66, an auxiliary power supply voltage of 12V, and a weight of 5.2KG. This is a highly efficient EV controller.
